Custom Rubber Coating Machine for Clutch Facing Production

  • Product Introduction:

    Suitable for the rubber coating process for yarn during the production of clutch facing. It’s equipped with 65mm diameter rubber extruder with the extrusion capacity of about 85kg per hour. It’s matched with the three-hole extrusion mold,which is capable of coating three-core flat or round tapes; Just change the mold core and mold sleeve,which will be OK.

  • Advantages:
    This unit consists of 9 pay-off frames; resin tank;Φ65 rubber extruder; double-wheel tractor and take-up stand.This unit adopts frequency conversion to control the speed increase of main machine and traction, and the temperature control of machine head mold and screw is controlled by the setting of mold temperature machine.

Product Introduction

Processing range: Yarn core Φ1.6~Φ2.5mm (The yarn core must withstand the pulling force of more than 15kg.)

Users can design molds according to product requirements.

Line speed range: Min: 3 m/min, Max: 20 m/min

Machine Controller: PLC Human-Machine Touch Control System

Size:17000*2000*2000mm(L*W*H)

Weight:about 3500kg

Rubber Coating Machine for Clutch Facing

Product Advantages

  • 01Stable & Reliable, Superior Performance.
  • 02High Quality, Cost-effective Price and Stable Quality.
  • 03Efficiency & Convenience,Ultra-high Precision.
  • 04Timely Response, Worry-free After-Sales Service.
  • 05Advanced Technology, Labor Saving.
  • 06Intelligent Control, Fast Changeover.
  • 07Customized Service, Strong Practicality.
  • 08Environmental Protection and Safety, Ultra-low Energy Consumption.

Scope of Application

  • 01Automatic clutch facing manufacturing machine.
  • 02Super wear resistant heavy truck clutch facing machine.
  • 03Stable friction coefficient car clutch facing supplier.
  • 04Automatic clutch facing production line machine.
  • 05Automatic clutch facing making machine.
  • 06Automatic clutch facing producing machine.
  • 07Passenger car clutch facing processing machine.
  • 08Producing machines for c.v. clutch facing.
